Booster Robotics · Humanoid
Booster K1
Portable & Ready to Go. A compact humanoid that fits in a single case for global transport without disassembly.
Platform Overview
The Booster K1 is a precise and powerful humanoid platform engineered for diverse applications. Designed to be portable and ready to go out of the box, it requires no disassembly and fits into a single transport case. Despite its compact 95cm height and ~19.5kg weight, it delivers impressive performance with edge-ready computing supporting 100-200 TOPS. It provides high-performance computing, fast response times, and a highly durable design.
Technical Specs
- Dimensions & Weight
- 95 x 40 x 18 cm (Span: 39cm), ~19.5 kg
- Calf-Thigh Length
- 46 cm
- Joint Ranges (Hip)
- 171° ~ -126°, 22° ~ -89°
- Joint Ranges (Knee & Ankle)
- Knee: 0° ~ 127°, Ankle: 50° ~ -20°, 20° ~ -20°
- Max Knee Torque
- 60 N.m
- Compute Performance
- Supports 100-200 TOPS
- Battery & Power
- 1h 20min (walking), 48V 5Ah
- Vision & Sensors
- Depth Camera, 9-Axis IMU
- Hardware Interfaces
- 1x Power Button, 3x Interaction Buttons, Indicator Light
Key Features
- Affordable for Every Need: Versatile and user-friendly for middle school and undergraduate students.
- Portable form factor: 95x40x18cm, ~19.5kg, fits in a single transport case without disassembly
- Degrees of Freedom: 6 DoFs per leg, ensuring highly agile locomotion
- Precise Control: Knee joint torque up to 60 N.m with dual encoders
- Smart System: Low battery and joint overheating reminders
- Perception & Audio: Depth Camera, 9-Axis IMU, Microphone Array & Speaker
- Advanced Connectivity: Gigabit Ethernet RJ45, Wi-Fi, and Bluetooth
- Developer friendly: Full secondary development support and OTA Firmware Upgrades
Open Source & Certified
Booster robots are fully open-source. Our robots also have all the CE certifications to be shipped in Europe.
Typical Use Cases
- Undergraduate and graduate robotics laboratories
- RoboCup-style competitions and capstone engineering projects
- STEM outreach programmes requiring demonstrable, engaging hardware
- Summer schools and corporate academies teaching mobile robotics
